HPE2-W09 Aruba Data Center Network Specialist Exam Questions and Answers

Refer to the exhibit.

Refer to the exhibit.

You are adding a VLAN 30, subnet 10.0.30.0/24 to the network shown in the exhibit. (This network is simplified to just the relevant switches for this item.) This subnet belongs in VRF A, and you have added a Layer 3 VLAN 30 interface attached to this VRF on Switch-1. You want to make the services in this VLAN available to devices in 10.1.20.0/24 in VRF B.

Is this part of a valid setup for meeting these requirements?

Solution:Add VRF B as the secondary VRF on VLAN interface 30.

Is this something that NetEdit 2.0 does after it discovers a switch?

Solution:It enables the switch REST API Interface, if disabled.

Refer to the exhibit.

which shows the topology tot an Ethernet Ring Protection Switching (ERPS) solution.

Is this a valid design for the control and protected VLANs on the VSX fabric 1 switches?

Solution:Ring 1, instance 1:

control VLAN: 1000protected VLANs: 51-135 Ring l,Instance2:

control VLAN: 1001 protected VLANs: 136-220 Ring 2, Instance 1: control VLAN: 1000 protected VLANs: 181 -200 Ring 2, Instance 2: control VLAN: 1003 protected VLANs: 201 -220

Does this correctly describehow the Virtual Switching Extension (VSX) fabric reacts to various component failure scenarios?

Solution:The keepalive goes down, ISL link remains up. Switch-1 and Switch-2 remains up. The Split-recovery mode is disabled. In this case the secondary switch shutdowns Svls.

Does this correctly describehow the Virtual Switching Extension (VSX) fabric reacts to various component failure scenarios?

Solution:The ISL and keepalive goes down, and after a few seconds, the keepalive link restores. Switch-l and Switch-2 remains up. The Split-recovery mode is enabled. In this case the secondary switch shutdowns SVls when keepalive is restored.

Does this correctly describethe ArubaOS-CX architecture?

Solution:The ArubaOS-CX time-series database helps to support network analytics and troubleshooting.

Is this a best practice when positioning ArubaOS-CX switches in data center networks?

Solution:Deploy Aruba CX 83xx switches as data center spine switches.

You plan to use multi-protocol BGP to implement dynamic VRF route leaking on an ArubaOS-CX switch.

Is this a rule for the setup?

Solution:You can only leak routes between up to three VRFs.
