H35-580_V2.0 HCIA-5G-RNP&RNO V2.0 Questions and Answers

According to the LTE user plane protocol stack, the Layer 3 of the Uu interface consists of the RRC protocol and the IP data. The RRC protocol is responsible for radio resource management, access control, handover and mobility, and encryption and integrity protection. The IP data is the payload of the user plane that is transmitted over the PDCP layer.

According to the HCIA-5G V2.0 Exam Outline, base station receive diversity gain is a factor that affects uplink coverage, not downlink coverage. Downlink coverage is affected by factors such as downlink path loss, downlink transmit power, and antenna gain, which correspond to options B, C, and D.

According to the HCIA-5G - Huawei Enterprise Support Community, reflection in a large amount of water and signals traveling far along a street due to the waveguide effect are common causes of overshoot coverage, which correspond to options A and C.

 According to the Hardware Description: Bbu5900 V100r013c10, the slot distribution in BBU5900 is not the same as that in BBU3910. The BBU5900 has 11 slots, while the BBU3910 has 12 slots. The slot distribution in BBU5900 is as follows:

A screenshot of a computer Description automatically generated

The Rayce ray tracing model is a propagation model that computes propagation paths using 3-D environment geometry 3. It is based on the shooting and bouncing rays (SBR) method, which launches rays from the transmitter and traces their reflections and diffractions until they reach the receiver or are attenuated below a threshold 4. The Rayce ray tracing model offers more accurate path searching, reflection, and diffraction energy calculation for electromagnetic wave propagation than other models, such as empirical models or deterministic models 5. It also offers higher level prediction accuracy, especially for massive MIMO systems that use beamforming techniques 6. The Rayce ray tracing model is not applicable only to C-band, but also to mmWave and other frequency bands 7.

According to the HCIA-5G V2.0 Exam Outline, the statements in options A, B, and C are correct descriptions of throughput-related indicators, which correspond to options A, B, and C. The statement in option D is incorrect because adding the last small packet of each data transmission burst and its transmission duration will reduce the accuracy of throughput measurement.

According to the HCIA-5G V2.0 Exam Outline, SDAP is a new protocol layer added to the 5G air interface protocol stack compared with 4G. SDAP stands for Service Data Adaptation Protocol, and it is used to map QoS flows to data radio bearers and perform header compression and decompression.

According to the HCIA-5G V2.0 Exam Outline, in the NSA DC architecture, when a UE moves to a neighboring gNodeB, the SgNB change procedure is triggered, which corresponds to option D.

According to the Probe User Guide (V100R019C10_01) (PDF)-EN, the Probe’s BLER statistics menu provides the following statistics:

• DIBLER: Downlink Initial Block Error Rate, which is the ratio of the number of erroneous downlink transport blocks to the total number of downlink transport blocks received by the UE in the first transmission.
• DRBLER: Downlink Residual Block Error Rate, which is the ratio of the number of erroneous downlink transport blocks to the total number of downlink transport blocks received by the UE after all retransmissions.
• Retransmission ratio: The ratio of the number of retransmitted downlink transport blocks to the total number of downlink transport blocks received by the UE.

The Probe’s BLER statistics menu does not provide the modulation scheme as a statistic. The modulation scheme is a parameter that determines the modulation and coding scheme (MCS) used for data transmission on the physical downlink shared channel (PDSCH). The modulation scheme can be QPSK, 16QAM, 64QAM, or 256QAM. The modulation scheme can be displayed on the Probe’s PDSCH configuration menu or PDSCH demodulation menu.

Therefore, the correct answer is A, B, and D.

According to the HCIA-5G V2.0 Exam Outline, SS-RSRP is the reference signal received power of the synchronization signal block (SSB) in NR systems. It can be used for measurement evaluation in idle mode during coverage problem analysis, which corresponds to option D. OPMI is an indicator of uplink interference power measurement, CSI-RSRP is the reference signal received power of the channel state information reference signal (CSI-RS), and SRS is the sounding reference signal. These indicators are used for measurement evaluation in connected mode, not idle mode, which correspond to options A, B, and C.

According to the 5G NR Downlink CSI Reporting, CSI-RS is the channel/signal that is used by the UE to measure and obtain the CQI. CSI-RS stands for Channel State Information Reference Signal, which is a downlink reference signal transmitted by the gNodeB to enable the UE to estimate the channel quality and feedback the CQI to the gNodeB. The CQI is an indicator of how good or bad the channel quality is, and it can be used by the gNodeB to adjust the modulation and coding scheme for data transmission.

According to the HCIA-5G V2.0 Exam Outline, no response from the UE, insufficient radio resources, and unauthorized UE are cause values of QoS flow setup failures, which correspond to options A, B, and D. Insufficient transmission resources is not a cause value of QoS flow setup failures, but a cause value of handover execution failures, which corresponds to option C.

According to the NR-ARFCN (NR absolute radio frequency channel number), the NR-ARFCN value consists of two components: the band indicator and the channel number. The band indicator represents the frequency band on which the carrier frequency lies, while the channel number represents the specific carrier frequency within that band. The NR-ARFCN value is calculated by the following formula:

NR-ARFCN = FREF-Offs + NREF-Offs + ΔFGlobal * (Fcarrier - FREF-Offs) / AFGIobal

where FREF-Offs is the reference frequency offset, NREF-Offs is the reference NR-ARFCN offset, ΔFGlobal is the global frequency raster, Fcarrier is the carrier frequency, and AFGIobal is the absolute frequency granularity.

Given that AFGIobal is 15 kHz, FREF-Offs is 3000 MHz, and NREF-Offs is 600000, we can plug in these values and Fcarrier = 3300 MHz into the formula and get:

NR-ARFCN = 3000 + 600000 + 5 * (3300 - 3000) / 0.015 NR-ARFCN = 633000

Therefore, the correct answer is A.

According to the Radio Resource Control, the maximum number of RRC_CONNECTED UEs depends on the number of available C-RNTIs (Cell Radio Network Temporary Identifiers) in a cell. The number of C-RNTIs is limited by the size of the RNTI field in the DCI (Downlink Control Information) format. For NR TDD cells, the RNTI field size is 16 bits, which allows up to 65,536 C-RNTIs. For NR FDD cells, the RNTI field size is 14 bits, which allows up to 16,384 C-RNTIs. Therefore, an NR TDD cell can support more RRC_CONNECTED UEs than an NR FDD cell under the same gNodeB.

According to the HCIA-5G V2.0 Exam Outline, cell unavailability due to system faults (specified using N.Cell.Unavail.Dur.System) is caused by factors such as CPRI link faults, board faults, and faults on an RF module’s TX or RX channels, which correspond to options A, C, and D. Blocking cells by using MML commands is not a system fault, but a manual operation, which corresponds to option B.
