C_ABAPD_2309 SAP Certified Associate - Back-End Developer - ABAP Cloud Questions and Answers

A metadata extension is a RESTful Application Programming object that can be used to organize the display of fields in an app. A metadata extension is a CDS view that annotates another CDS view with UI annotations, such as labels, icons, or facets. These annotations define how the data should be presented in the app, such as which fields should be shown on the object page, which fields should be editable, or which fields should be used for filtering or sorting. A metadata extension can also be used to add custom actions or validations to the app12. References: 1: Refine the Object Page with Annotations | SAP Tutorials 2: ABAP RAP : Enabling custom actions with a dialog for additional input fields | SAP Blogs

The following are the explanations for each ABAP SQL statement:

A: This statement is valid. It selects the fields carrid, airpfrom, and the aggregate functions MAX(distance) and MIN(distance) from the table /dmo/connection, and groups the results by carrid and airpfrom. The aggregate functions are aliased as dist_max and dist_min. The results are stored in an internal table named It_hits, which is created using the inline declaration operator @DATA.

B: This statement is valid. It is similar to statement A, except that it does not specify the GROUP BY clause. This means that the aggregate functions are applied to the entire table, and the results are stored in an internal table named It_hits, which is created using the inline declaration operator @DATA.

C: This statement is invalid. It selects the aggregate functions MAX(distance) and MIN(distance) from the table /dmo/connection, but it does not specify any grouping or non-aggregate fields. This is not allowed in ABAP SQL, as the SELECT list must contain at least one non-aggregate field or a GROUP BY clause. The statement will cause a syntax error.

D: This statement is invalid. It selects the fields carrid and airpfrom from the table /dmo/connection, and groups the results by carrid and connid. However, the field connid is not included in the SELECT list, which is not allowed in ABAP SQL, as the GROUP BY clause must contain only fields that are also in the SELECT list. The statement will cause a syntax error.

References: SELECT - ABAP Keyword Documentation, GROUP BY - ABAP Keyword Documentation

The response will be an activation error because the field names of the union do not match. This is because the field names of the union must match in order for the definition to be activated. The union operator combines the result sets of two or more queries into a single result set. The queries that are joined by the union operator must have the same number and type of fields, and the fields must have the same names1. In the given code, the field names of the union do not match, because the first query has the fields carrname, connid, cityfrom, and cityto, while the second query has the fields carrname, carrier_id, cityfrom, and cityto. The field connid in the first query does not match the field carrier_id in the second query. Therefore, the definition cannot be activated.

References: 1: UNION - ABAP Keyword Documentation

 In class ZCL_CLASS_A, you use the statement DATA var TYPE *** to declare a data object named var with a data type specified by ***. The data type can be any of the following1:

A predefined ABAP type, such as i, f, c, string, xstring, and so on.

A data element from the ABAP Dictionary, such as matnr, carrid, bukrs, and so on. A data element defines the semantic and technical attributes of a data field, such as the domain, the length, the data type, the description, and the value range2.

A domain from the ABAP Dictionary, such as matnr_d, carrid_d, bukrs_d, and so on. A domain defines the technical attributes of a data field, such as the data type, the length, the output length, the number of decimal places, and the value range3.

A type defined globally in a class, an interface, or a type pool, such as zcl_class_b=>type_a, zif_interface_c=>type_b, ztype_pool_d=>type_c, and so on. A global type is a type that is defined in a global repository object and can be used in any program or class4.

A type defined locally in the current class, such as type_a, type_b, type_c, and so on. A local type is a type that is defined in the declaration part of a class and can only be used within the class5.

Therefore, the possible values for *** are B. the name of a data element from the ABAP Dictionary and D. the name of a domain from the ABAP Dictionary. The other options are not valid because:

A. The name of a type defined privately in class ZCL_CLASS_A is a local type and cannot be used with the DATA statement. A local type can only be used with the TYPES statement5.

C. The name of a type defined privately in another class is a private type and cannot be accessed from outside the class. A private type can only be used within the class that defines it.

References: 1: DATA - ABAP Keyword Documentation 2: Data Elements - ABAP Dictionary - SAP Online Help 3: Domains - ABAP Dictionary - SAP Online Help 4: Global Types - ABAP Keyword Documentation 5: Local Types - ABAP Keyword Documentation : Private Types - ABAP Keyword Documentation

Secondary keys are additional keys that can be defined for internal tables to optimize the access to the table using fields that are not part of the primary key. Secondary keys can be either sorted or hashed, depending on the table type and the uniqueness of the key. Secondary keys have the following characteristics1:

A. Secondary keys must be chosen explicitly when you actually read from an internal table. This means that when you use a READ TABLE or a LOOP AT statement to access an internal table, you have to specify the secondary key that you want to use with the USING KEY addition. For example, the following statement reads an internal table itab using a secondary key sec_key:

READ TABLE itab USING KEY sec_key INTO DATA(wa).

If you do not specify the secondary key, the system will use the primary key by default2.

B. Multiple secondary keys are allowed for any kind of internal table. This means that you can define more than one secondary key for an internal table, regardless of the table type. For example, the following statement defines an internal table itab with two secondary keys sec_key_1 and sec_key_2:

DATA itab TYPE SORTED TABLE OF ty_itab WITH NON-UNIQUE KEY sec_key_1 COMPONENTS field1 field2 sec_key_2 COMPONENTS field3 field4.

You can then choose which secondary key to use when you access the internal table1.

D. Sorted secondary keys do NOT have to be unique. This means that you can define a sorted secondary key for an internal table that allows duplicate values for the key fields. A sorted secondary key maintains a predefined sorting order for the internal table, which is defined by the key fields in the order in which they are specified. For example, the following statement defines a sorted secondary key sec_key for an internal table itab that sorts the table by field1 in ascending order and field2 in descending order:

DATA itab TYPE STANDARD TABLE OF ty_itab WITH NON-UNIQUE SORTED KEY sec_key COMPONENTS field1 ASCENDING field2 DESCENDING.

You can then access the internal table using the sorted secondary key with a binary search algorithm, which is faster than a linear search3.

The following are not characteristics of secondary keys for internal tables, because:

C. Hashed secondary keys do NOT have to be unique. This is false because hashed secondary keys must be unique. This means that you can only define a hashed secondary key for an internal table that does not allow duplicate values for the key fields. A hashed secondary key does not have a predefined sorting order for the internal table, but uses a hash algorithm to store and access the table rows. For example, the following statement defines a hashed secondary key sec_key for an internal table itab that hashes the table by field1 and field2:

DATA itab TYPE STANDARD TABLE OF ty_itab WITH UNIQUE HASHED KEY sec_key COMPONENTS field1 field2.

You can then access the internal table using the hashed secondary key with a direct access algorithm, which is very fast.

E. Secondary keys can only be created for standard tables. This is false because secondary keys can be created for any kind of internal table, such as standard tables, sorted tables, and hashed tables. However, the type of the secondary key depends on the type of the internal table. For example, a standard table can have sorted or hashed secondary keys, a sorted table can have sorted secondary keys, and a hashed table can have hashed secondary keys1.

References: 1: Secondary Table Key - ABAP Keyword Documentation 2: READ TABLE - ABAP Keyword Documentation 3: Sorted Tables - ABAP Keyword Documentation : Hashed Tables - ABAP Keyword Documentation

When processing a loop with the statement DO… ENDDO, the system variable that contains the implicit loop counter is sy-index. The loop counter is a numeric value that indicates how many times the loop has been executed. The loop counter is initialized to 1 before the first execution of the loop and is incremented by 1 after each execution. The loop counter can be used to control the number of loop iterations or to access the loop elements by index. The loop counter can also be accessed or modified within the loop body, but this is not recommended as it may cause unexpected results or errors1.

For example, the following code snippet uses the loop counter sy-index to display the numbers from 1 to 10:

DO 10 TIMES. WRITE: / sy-index. ENDDO.

The output of this code is:

1 2 3 4 5 6 7 8 9 10

References: 1: DO - ABAP Keyword Documentation

The purpose of a foreign key relationship between two tables in the ABAP Dictionary is to ensure the integrity of data in the corresponding database tables. A foreign key relationship defines a logical link between a foreign key table and a check table, where the foreign key fields of the former are assigned to the primary key fields of the latter. This means that the values entered in the foreign key fields must exist in the check table, otherwise the system will reject the entry. This way, the foreign key relationship prevents the insertion of invalid or inconsistent data in the database tables.

A foreign key relationship also serves to document the relationship between the two tables in the ABAP Dictionary, but this is not its primary purpose. A foreign key relationship does not necessarily create a corresponding foreign key relationship in the database, as this depends on the database system and the settings of the ABAP Dictionary. Some database systems do not support foreign keys at all, while others require additional steps to activate them. Therefore, the foreign key relationship in the ABAP Dictionary is mainly a logical concept that is enforced by the ABAP runtime environment.

References: Foreign Keys (SAP Library - ABAP Dictionary), Foreign Keys (SAP Library - BC - ABAP Dictionary)

https://help.sap.com/doc/saphelp_snc70/7.0/en-US/cf/21ea77446011d189700000e8322d00/content.htm

String functions are expressions that can be used to manipulate character-like data in ABAP. String functions can be either predicate functions or non-predicate functions. Predicate functions are string functions that return a truth value (true or false) for a condition of the argument text. Non-predicate functions are string functions that return a character-like result for an operation on the argument text1.

The following string functions are predicate functions:

B. contains_any_of(): This function returns true if the argument text contains at least one of the characters specified in the character set. For example, the following expression returns true, because the text ‘ABAP’ contains at least one of the characters ‘A’, ‘B’, or ‘C’:

contains_any_of( val = ‘ABAP’ set = ‘ABC’ ).

D. matches(): This function returns true if the argument text matches the pattern specified in the regular expression. For example, the following expression returns true, because the text ‘ABAP’ matches the pattern that consists of four uppercase letters:

matches( val = ‘ABAP’ regex = ‘[A-Z]{4}’ ).

The following string functions are not predicate functions, because they return a character-like result, not a truth value:

A. find_any_not_of(): This function returns the position of the first character in the argument text that is not contained in the character set. If no such character is found, the function returns 0. For example, the following expression returns 3, because the third character of the text ‘ABAP’ is not contained in the character set ‘ABC’:

find_any_not_of( val = ‘ABAP’ set = ‘ABC’ ).

C. count_any_of(): This function returns the number of characters in the argument text that are contained in the character set. For example, the following expression returns 2, because there are two characters in the text ‘ABAP’ that are contained in the character set ‘ABC’:

count_any_of( val = ‘ABAP’ set = ‘ABC’ ).

References: 1: String Functions - ABAP Keyword Documentation

A field symbol is a pointer that allows direct access to a row of an internal table without copying it to a work area. Using a field symbol for internal table row access has some advantages over using a work area, such as12:

A MODIFY statement to write changed contents back to the table is not required: This is true. When you use a work area, you have to copy the row content from the internal table to the work area, modify it, and then copy it back to the internal table using the MODIFY statement. This can be costly in terms of performance and memory consumption. When you use a field symbol, you can modify the row content directly in the internal table without any copying. Therefore, you do not need the MODIFY statement12.

Using a field symbol is faster than using a work area: This is true. As explained above, using a field symbol avoids the overhead of copying data between the internal table and the work area. This can improve the performance of the loop considerably, especially for large internal tables. According to some benchmarks, using a field symbol can save 25–40% of the runtime compared to using a work area12.

You cannot do any of the following:

The field symbol can be reused for other programs: This is false. A field symbol is a local variable that is only visible within the scope of its declaration. It cannot be reused for other programs unless it is declared globally or passed as a parameter. Moreover, a field symbol must have the same type as the line type of the internal table that it accesses. Therefore, it cannot be used for any internal table with a different line type12.

The row content is copied to the field symbol instead to a work area: This is false. As explained above, using a field symbol does not copy the row content to the field symbol. Instead, the field symbol points to the memory address of the row in the internal table and allows direct access to it. Therefore, there is no copying involved when using a field symbol12.

References: 1: Using Field Symbols to Process Internal Tables - SAP Learning 2: Access to Internal Tables - ABAP Keyword Documentation - SAP Online Help

The code snippet in the image is an example of using the RAISE EXCEPTION statement to raise a class-based exception and create a corresponding exception object. The code snippet also uses the EXPORTING addition to pass parameters to the instance constructor of the exception class12. Some of the valid statements about the code snippet are:

The code creates an exception object and raises an exception: This is true. The RAISE EXCEPTION statement raises the exception linked to the exception class zcxl and generates a corresponding exception object. The exception object contains the information about the exception, such as the message, the source position, and the previous exception12.

“previous” expects the reference to a previous exception: This is true. The previous parameter is a predefined parameter of the instance constructor of the exception class cx_root, which is the root class of all class-based exceptions. The previous parameter expects the reference to a previous exception object that was caught during exception handling. The previous parameter can be used to chain multiple exceptions and preserve the original cause of the exception12.

You cannot do any of the following:

“zcxl” is a dictionary structure, and “paraml” and “param2” are this structure: This is false. zcxl is not a dictionary structure, but a user-defined exception class that inherits from the predefined exception class cx_static_check. param1 and param2 are not components of this structure, but input parameters of the instance constructor of the exception class zcxl. The input parameters can be used to pass additional information to the exception object, such as the values that caused the exception12.

“paraml” and “param2” are predefined names: This is false. param1 and param2 are not predefined names, but user-defined names that can be chosen arbitrarily. However, they must match the names of the input parameters of the instance constructor of the exception class zcxl. The names of the input parameters can be declared in the interface of the exception class using the RAISING addition12.

References: 1: RAISE EXCEPTION - ABAP Keyword Documentation - SAP Online Help 2: Class-Based Exceptions - ABAP Keyword Documentation - SAP Online Help

ABAP SQL arithmetic expressions have different restrictions depending on the data type of the operands. The following are some of the restrictions:

Floating point types and integer types can be used in the same expression, as long as the integer types are cast to floating point types using the cast function. For example, CAST ( num1 AS FLTP ) / CAST ( num2 AS FLTP ) is a valid expression, where num1 and num2 are integer types.

The operator / is allowed only in floating point expressions, where both operands have the type FLTP or f. For example, num1 / num2 is a valid expression, where num1 and num2 are floating point types. If the operator / is used in an integer expression or a decimal expression, a syntax error occurs.

Decimal types and integer types can be used in the same expression, as long as the expression is a decimal expression. A decimal expression has at least one operand with the type DEC, CURR, or QUAN or p with decimal places. For example, num1 + num2 is a valid expression, where num1 is a decimal type and num2 is an integer type.

The operator ** is allowed only in floating point expressions, where both operands have the type FLTP or f. For example, num1 ** num2 is a valid expression, where num1 and num2 are floating point types. If the operator ** is used in an integer expression or a decimal expression, a syntax error occurs.

References: sql_exp - sql_arith - ABAP Keyword Documentation, SQL Expressions, Arithmetic Calculations - ABAP Keyword Documentation

The sub constructor is the instance constructor of the subclass sub that inherits from the superclass super. The sub constructor has some rules that it must follow when it is defined and implemented12. Some of the valid rules are:

The method signature can be changed: This is true. The sub constructor can have a different method signature than the super constructor, which means that it can have different input parameters, output parameters, or exceptions. However, the sub constructor must still call the super constructor with appropriate actual parameters that match its interface12.

The constructor of super must be called before using any components of your own instance: This is true. The sub constructor must ensure that the super constructor is called explicitly using super->constructor before accessing any instance components of its own class, such as attributes or methods. This is because the super constructor initializes the inherited components of the subclass and sets the self-reference me-> to the current instance12.

You cannot do any of the following:

Import parameters can only be evaluated after calling the constructor of super: This is false. The sub constructor can evaluate its own import parameters before calling the constructor of super, as long as it does not access any instance components of its own class. For example, the sub constructor can use its import parameters to calculate some values or check some conditions that are needed for calling the super constructor12.

Events of your own instance cannot be raised before the registration of a handler in super: This is false. The sub constructor can raise events of its own instance before calling the constructor of super, as long as it does not access any instance components of its own class. For example, the sub constructor can raise an event to notify the consumers of the subclass about some status or error that occurred during the initialization of the subclass12.

References: 1: Inheritance and Constructors - ABAP Keyword Documentation - SAP Online Help 2: Using Static and Instance constructor methods | SAP Blogs

On-stack developer extensibility is a type of extensibility that allows you to create development projects directly on the SAP S/4HANA Cloud technology stack. It gives you the opportunity to develop cloud-ready and upgrade-stable custom ABAP applications and services inside the SAP S/4HANA Cloud, public edition system. You can use the ABAP Development Tools in Eclipse to create and deploy your on-stack extensions. On-stack developer extensibility is suitable for the following kinds of applications:

Applications that provide APIs for side by side SAP BTP apps. On-stack developer extensibility allows you to create OData services or RESTful APIs based on CDS view entities or projection views. These services or APIs can expose SAP S/4HANA data and logic to other applications that run on the SAP Business Technology Platform (SAP BTP) or other platforms. This way, you can create a loosely coupled integration between your SAP S/4HANA system and your side by side SAP BTP apps.

Applications that access SAP S/4HANA data using complex SQL. On-stack developer extensibility allows you to use ABAP SQL to access SAP S/4HANA data using complex queries, such as joins, aggregations, filters, parameters, and code pushdown techniques. You can also use ABAP SQL to perform data manipulation operations, such as insert, update, delete, and upsert. This way, you can create applications that require advanced data processing and analysis on SAP S/4HANA data.

The other kinds of applications are not suitable for on-stack developer extensibility, as they have different requirements and challenges. These kinds of applications are:

Applications that integrate data from several different systems. On-stack developer extensibility is not meant for creating applications that integrate data from multiple sources, such as other SAP systems, third-party systems, or cloud services. This is because on-stack developer extensibility does not support remote access or data replication, and it may cause performance or security issues. For this kind of applications, you should use side by side extensibility, which allows you to create applications that run on the SAP BTP and communicate with the SAP S/4HANA system via public APIs or events.

Applications that run separate from SAP S/4HANA. On-stack developer extensibility is not meant for creating applications that run independently from the SAP S/4HANA system, such as standalone apps, microservices, or web apps. This is because on-stack developer extensibility requires a tight coupling with the SAP S/4HANA system, and it may limit the scalability, flexibility, and portability of the applications. For this kind of applications, you should use side by side extensibility, which allows you to create applications that run on the SAP BTP and leverage the cloud-native features and services of the platform.

References: Developer Extensibility in SAP S/4HANA Cloud ABAP Environment, SAP S/4HANA Extensibility – Simplified Guide for Beginners

The data type of gv_result in the assignment data (gv_result) = 1/8 will be TYPE DECFLOAT 16. This is because the assignment operator (=) in ABAP performs an implicit type conversion from the source type to the target type, according to the following rules12:

If the target type is specified explicitly, the source value is converted to the target type.

If the target type is not specified explicitly, the source type is used as the target type, unless the source type is a literal or an expression, in which case the target type is determined by the following priority order: DECFLOAT34, DECFLOAT16, P, F, I, C, N, X, STRING, XSTRING.

In this case, the target type is not specified explicitly, and the source type is an expression (1/8). Therefore, the target type is determined by the priority order, and the first matching type is DECFLOAT16, which is a decimal floating point type with 16 digits of precision12.

References: 1: ABAP Assignment Rules - ABAP Keyword Documentation - SAP Online Help 2: ABAP Data Types - ABAP Keyword Documentation - SAP Online Help

The order in which the join statements will be executed is:

scarr will be joined with scounter first and the result will be joined with sairport.

This is because the join statements are nested from left to right, meaning that the leftmost data source is joined with the next data source, and the result is joined with the next data source, and so on. The join condition for each pair of data sources is specified by the ON clause that follows the data source name. The join type for each pair of data sources is specified by the join operator that precedes the data source name. In this case, the join operator is LEFT OUTER JOIN, which means that all the rows from the left data source are included in the result, and only the matching rows from the right data source are included. If there is no matching row from the right data source, the corresponding fields are filled with initial values1.

Therefore, the join statements will be executed as follows:

First, scarr AS a will be joined with scounter AS c using the join condition a.carrid = c.carrid. This means that all the rows from scarr will be included in the result, and only the rows from scounter that have the same value for the carrid field will be included. If there is no matching row from scounter, the countnum field will be filled with an initial value.

Second, the result of the first join will be joined with sairport AS p using the join condition p.id = c.airport. This means that all the rows from the first join will be included in the result, and only the rows from sairport that have the same value for the id field as the airport field from the first join will be included. If there is no matching row from sairport, the id field will be filled with an initial value.

References: 1: Join - ABAP Keyword Documentation

In RESTful Application Programming, the EML statement that retrieves an object is GET entity. The GET entity statement is used to read data of an entity instance from the database or the transaction buffer. The GET entity statement can specify the entity name, the entity key, and the entity elements to be retrieved. The GET entity statement can also use the IN LOCAL MODE addition to bypass the access control, authorization control, and feature control checks. The GET entity statement returns a single entity instance or raises an exception if no instance is found or multiple instances match the key.

The other EML statements are not used to retrieve an object, but have different purposes and effects. These statements are:

FIND entity: This statement is used to search for entity instances that match a given condition. The FIND entity statement can specify the entity name, the entity elements to be returned, and the condition to be applied. The FIND entity statement can also use the IN LOCAL MODE addition to bypass the access control, authorization control, and feature control checks. The FIND entity statement returns a table of entity instances or an empty table if no instances match the condition.

SELECT entity: This statement is used to query data of entity instances from the database or the transaction buffer. The SELECT entity statement can specify the entity name, the entity elements to be returned, and the filter, order, and aggregation options to be applied. The SELECT entity statement can also use the IN LOCAL MODE addition to bypass the access control, authorization control, and feature control checks. The SELECT entity statement returns a table of entity instances or an empty table if no instances match the query.

READ entity: This statement is not a valid EML statement, but an ABAP statement. The READ statement is used to access a single row of an internal table using the table index or the table key. The READ statement can also use the TRANSPORTING addition to specify which fields should be returned, and the INTO addition to specify the target variable. The READ statement returns a single row of the internal table or raises an exception if no row is found or multiple rows match the key.

References: GET ENTITY - ABAP Keyword Documentation, FIND ENTITY, ENTITIES - ABAP Keyword Documentation, SELECT ENTITY, ENTITIES - ABAP Keyword Documentation, READ - ABAP Keyword Documentation
